Model No.

NST-IPH7473-VR

NST-IPH74713-VR

Image Sensor

1/3" CMOS sensor

Resulation

1536x1536(3.0MP)

1280x960(1.3MP)

Lenses

1.19mm viewing Angle:360°

1.44mm viewing Angle:360°

PTZ

360°

Day & Night

IR-cut Double filter automatic switching

Nimum illumination

0.1 Lux @(F2.0,AGC ON), 0.01 Lux with IR

Video Compression Standard

H.264

Video Compression Code Stream

HD(2.4M)Smooth(VGA)

HD(960P)fluent(VGA)

Audio Source

Passive microphone

Audio Compression Standard

G711A

Audio Compression Code Stream

Streaming self-adaptive

Network Interface

1 RJ45 10M/100M self-adaptive Ethernet Port

WAP

Wi-Fi(IEEE802.11b)

Storage

Support Micro SD card(max128G)

IR distance

10-15M(Owing to the different environment)

Power consumption

≤6W

Power

12V

Working Temp

0~50℃ RH Less than 95%(No condensation)
