Product Description
Features:
Embedded algorithm with OCR (Optical Character Recognition) for recognition of license plates without the need for external software for image processing;
Motorized varifocal lens from 5 to 50mm allowing the capture of plates at a distance of up to 40 m. Allows zoom and remote focus facilitating equipment adjustments and configurations;
Recognition rate up to 99% with readable car plates and adequate lighting conditions;
Capture license plates with speeds up to 100km during the day and night;
Supports virtual loop detection, without the need for inductive loop, facilitating installation and reducing deployment time. Has the function of physical loop;
It has up to four light exposure profiles, facilitating adjustment at different times of the day;
Allows the definition of the area of interest, allowing the capture of signs only in the area of interest, increasing assertiveness and decreasing the need for communication bandwidth;
Has a micro SD memory card slot for internal storage up to 128GB;
Protective housing with anti-corrosion material and option for IK10 protection;
Internal power supply and optional POE power;
Specifications:
Model No. | NST-IPH5112-ANPR-TR | |
Recognition | Recognition Rate | > 99%, Time < 0.1s |
| Max. Speed | 150km/h Max. | |
| Type of Plate | Cars and Motorcycles | |
| Vehicle Detection | Virtual Trigger Line, Physical Inductive Loop, Combo | |
| Max. Capture Distance | 40m (Max.) | |
| Direction | Front, Rear, Both | |
| Camera | Image Sensor | 1/2.7" Cmos Sensor |
| Lens | Motorized Varifocal Lens 5-50mm With IR Correction | |
| Shutter Speed | 1/100~1/10000s | |
| IR Light | 4 LED IR Light With 1W each | |
| WDR | Yes | |
| HLC | Yes | |
| Video | Resolution | 1920 x 1080, 1280 x 720, CIF |
| Video Compression | H.264 / MJPEG | |
| Transmission band | 384Kbps~8Mbps | |
| Frame Rate | 30FPS | |
| Streams | Main Stream and Sub. Stream | |
| Function | Redundencia Transmission | 2 Server Simultaneously |
| Re-transmission | Yes | |
| ProtocoIos | IPv4, IPv6,TCP/IP, UDP, HTTP, HTTPs, DNS, NTP, FTP, ARP, RTSP, ICMP,IGMP Onvif-S | |
| Black List | 10K Registor | |
| Communication Security | Support Encrypt with CA Certificates | |
| Offline Download | Support Offline Charging Function | |
| Interface | Network | 1 Network interface 10/100Mbps, RJ45 |
| Serial Port | 2 x RS485 | |
| Alarm In | 2 x Alarm In | |
| Alarm Out | 2 x Alarm Out | |
| Reset Button | Yes | |
| Storage | Micro-SD Max. 128GB | |
| USB | 1 Interface USB Type A | |
| General | Power | Without IR <4W, With IR on < 9W |
| Working Envirment | -30 a +75oC, e RH 95% | |
| Protection | IP66, IK10 (Optional) | |
| Power supply | 90-220V AC, 12V DC, or POE (IEEE802.3af, 802.3at) | |
| Weight | 2.2Kg | |
