Product Description
|
Model No. |
NST-XVR6116NH
|
|
|
System
|
Main processor |
Technical grade embedded microprocessor HI 3521A |
|
Operating system |
Embedded LINUX operating system |
|
|
System resource |
Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up. |
|
|
Interface |
Operation interface |
16bit real color GUI interface support mouse operation |
|
Display screen |
1/4/8 screen (take analog channel as an example, other is base on the selected channel mode) |
|
|
Video
|
Video standard |
PAL/NTSC( 1080N ) |
|
Image encode |
H.264(High Profile);JPEG |
|
|
Monitor quality |
Monitor : D1 ; VGA , HDMI : High definition ( support 1920*1080, 1280*720,1440*900,1280*1024, 1024*768 、 800*600 ) |
|
|
Playback quality |
1080N/ D1/HD1/CIF |
|
|
Encode capability |
16*1080N |
|
|
Decode capability |
16*1080N |
|
|
Multi-mode video input |
AHD/CVI/TVI/ANALOG:16*1080N(12FPS),
HVR:8*1080N(AHD)+8*960P(IP) |
|
|
Motion detection |
Each channel can set 192(16*12)detection area;can set multi-level of flexibility (for local analog channel only) |
|
|
Audio |
Audio compression |
G711A |
|
Bidirectional talk |
support |
|
|
Record and playback |
Record mode |
manual > alarm > motion detection > timing |
|
Local playback |
1-9ch playback synchronously (take local analog input for example, other is depended on the selected channel mode) |
|
|
Video search |
time 、 date 、 event 、 channel search |
|
|
Storage and back up |
Space occupation |
Video:CIF 4~5G/day*channel, D1 16~20G/day*channel; |
|
Video storage |
Local HDD 、 Network |
|
|
Back up mode |
Network backup 、 USB portable HDD 、 USB imprint 、 SATA imprint |
|
|
Interface |
Video input |
8CH BNC(1.0Vp-p,75Ω) |
|
Video output |
1 CH VGA , 1 CH HDMI |
|
|
Audio input |
2CH RCA |
|
|
Audio output |
1 CH RCA(200-3000mV,5KΩ) |
|
|
Alarm input |
N/A |
|
|
Alarm output |
N/A |
|
|
Network port |
RJ45 10M/100M self-adaptive Ethernet port |
|
|
PTZ control |
1 RS485 ; support multi kinds of PTZ protocol |
|
|
USB port |
2 * USB 2.0 |
|
|
HDD port |
1 SATA ports ( each max to 6TB ) |
|
|
Wireless port |
3G 、 WIFI( extension via USB port ) |
|
|
other |
Power |
12V/ 2.5 A |
|
Consumption |
<15W ( not including HDD ) |
|
|
Temperature |
0 ℃ - + 55 ℃ |
|
|
Humidity |
10% - 90% |
|
|
Atmosphere pressure |
86kpa - 106kpa |
|
|
Dimension |
L255*W220*H45MM |
|
|
Weight |
1.2KG |
|
