Model No. | NST-IPM7108-AF10X | NST-IPM7105-AF10X | NST-IPH7103-AF10X | |
Camera Type | 10X Optical Zoom IP Security Camera AutoFocus 8MP 4K POE Security IP Camera | |||
System | Embedded RTOS design | |||
Camera | Effective Pixels | 8.0 Mega Pixels(4K) | 5.0 Megapixels | 3.0 Mega Pixels |
Main stream:3840*2160; | Main stream:2592*1944; | Main stream:2304*1296; | ||
Sub stream:1280*720,704*576 | Sub stream:704*576 | Sub stream:704*576 | ||
Frames Rates | PAL:20fps(3840*2160) | PAL:20fps(2592*1944) | PAL:25fps(1920*1080) | |
NTSC:20fps(3840*2160) | NTSC:20fps(2592*1944) | NSTC:30fps(1920*1080) | ||
Image Sensor | 1/2.8" SONY IMX415 CMOS Sensor | 1/2.8" SONY IMX335 CMOS Sensor | 1/2.8" SONY IMX307 CMOS Sensor | |
8 megapixel resolution (3864H*2202V) | 6 Megapixel resolution | 3 megapixel resolution | ||
DSP | Dual core 32-bit DSP | Dual core 32-bit DSP | Dual core 32-bit DSP | |
(SigmaStar) | (SigmaStar) | (SigmaStar) | ||
Min. Illumination | Color 0.001Lux@F1.2 | Color 0.001Lux@F1.2 | Color 0.01Lux@F1.2 | |
B/W 0.0001 Lux@F1.2 | B/W 0.001 Lux@F1.2 | B/W 0.01 Lux@F1.2 | ||
Adjust Parameters | WDR,BLC,DNR,AE,AGC,D&N,Mirror,Flip,etc. | |||
Video | Compression | H.265/H.264 Main profile | H.265/H.264 Main profile | H.265/H.264 Main profile |
Stream | support dual stream,AVI format | support dual stream,AVI format | support dual stream,AVI format | |
Bit Rate | support 0.1M ~8Mpbs bit rate adjustable | support 0.1M ~8Mpbs bit rate adjustable | support 0.1M ~8Mpbs bit rate adjustable | |
Frame Rates | support 1~30fps adjust | support 1~30fps adjust | support 1~30fps adjust | |
Audio | Input and output | 2Way Audio 1ch input micphone,1ch output Speaker | ||
Compression | AAC/G.711 compression,support two-way audio intercom,support audio and video synchronized output | |||
| PTZ | Pan/Tilt Range Pan | 0° to 355° endless Tilt: 0° to +90°, | ||
| Manual Control Speed | Pan: 2.3°/s–24.5 °/s Tilt: 2.5°/s–15 °/s | |||
| Preset Speed | Pan: 18 °/s Tilt: 12°/s | |||
| Preset | 30 | |||
| Cruise | 1 cruises lines,up to 30 presets | |||
| Power off memory | Yes | |||
| Intelligence | IVS (Perimeter Protection) | crossing fence detection; vehicle/human alarm classification | ||
Alarm | Types | Motion Detection, Video Blind , Video Loss | ||
Network | WEB Browser | Support WEB remote config( IE, Safari, Google Chrome, Firefox etc.) | ||
Smart Phone | mobile remote Monitoring (iPhone,Android,....) | |||
CMS Software | Uniform CMS Software(multiple devices management system) | |||
Cloud P2P | www.enster.com,MYEYE platform and other program,Offer SDK | |||
Network | 1 * RJ45,10/100M,Support RTMP/RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/SMTP | |||
Interoperability | CGI; SDK; ONVIF (Profile S&G&T) | |||
POE | Support(optional) | |||
WIFI | N/A | |||
General | Language | 20 kinds of languages such as English, Finnish, French, German, Greek,Italian, Japanese, Polish, Portuguese, Russian, Spanish, Thai, S-Chinese, T-Chinese and Turkish | ||
IR Cut Filter | Set of double light switch IR-CUT filter | |||
Lens Mount | 10X Motorized Zoom AutoFocus 5-50MM Lens(10X Digital Zoom) | |||
| Zoom Speed | <3S | |||
| Max. Aperture | F2.36-F2.4 | |||
| Angel of view | Horizontal filed of view: 63.49° (w)~6.6° (t) Vertical field of view: 36.32° (w)~3.8° (t) Diagonal field of view:71.98°(w)~7.5°(t) | |||
| Focus Control | auto; manual | |||
| Iris Control | Auto; manual | |||
Aux Luminary | 8PCS IR LED/8PCS Whie Light LED | |||
| Illuminator On/Off Control | Manual; Smart IR; Off | |||
Infrared Wavelength | 850nm | |||
Illuminate Distance | 50m | |||
Waterproof Criterion | IP 66 | |||
I/O Connector | 1*DC Connector ,1* RJ45(10/100M Network) | |||
Supplied Voltage | DC12V/PoE(802.3af/820.3at) | |||
Power Consumption | IR On: 600mA max., IR Off: Less than 200mA | |||
Working Environment | -10°C~+60°C, 10%~90% ( Built in Heater being optional added for enviroment lower than -20° ) | |||
Weight | 1.5kg | |||
