Product Description
Model No. | X42TAC V5.5 | |
| Product accessories | 5V/1A USB charger (European regulation or American regulation) 1 | |
| BNC jumper 1 | ||
| DC - DC line 1 | ||
| Manual 1 | ||
| Optional accessories | toolbox | |
| Main component | The shell ABS. | |
| 7 inch LCD screen 800*480 | ||
| Battery: 18650 lithium battery 4, total 8800mAH, single section 2200mAh | ||
| Analog hd receiver module | ||
| Input/output display | TVI2.0 | 280*720@25 |
| 1280*720@25 | ||
| 1920*1080@25 | ||
| TVI3.0 | 2048*1536@18 | |
| TVI4.0 | 2560*1440@25 | |
| 2560*1944@20fps | ||
| 2560*1944@12.5fps | ||
| 2.AHD2.0 | 1280*720@2 | |
| 1920*1080@25 | ||
| AHD3.0 | 2048*1536@18fps | |
| 2560*1440@15fps | ||
| CVI2.0 | 1280*720@25 | |
| 1920*1080@25 | ||
| Supports simulation of CVBS signal PAL/NTSC | ||
| Support VGA/HDMI1.1 input maximum support of 1920*1080 | ||
| Support TVI ball machine coaxial visual control function, haikang vision coaxial vision control protocol: HIKVISION-C | ||
| No video signal access display color bar and CVBS analog output, access video to display video signal synchronization simulation CVBS video image signal output | ||
| Charge and output | The maximum voltage of the battery is 4.2 V, 2-4, 18650 parallel | |
| Use DC-DC line to lift 12V output, maximum discharge current 0.8 A. | ||
| 5V USB charger charging current 0.8 A, full of self-stop. Provide European or American regulations. | ||
| Power consumption | Start TVI power consumption: 4.2W | |
| Turn off TVI power: 2.5w | ||
| Size, weight | The maximum size of the naked machine: 204MM*144MM*43MM | |
| Machine net weight: 700g | ||
| Gross weight: 1.1kg | ||
| 10 / box gross weight: 12kg | ||
