NST-TSR01 is a 24GHz high-performance traffic speed radar that accurately measures vehicle speed and other information by using the frequency difference between the emitted radio waves and the echo. The TSR01 uses a micro strip array antenna design with accurate speed measurement and can distinguish between coming and going vehicles. Installed at the road side, it can automatically measure the driving speed of vehicles in 1 to 4 lanes.

NST-TSR01 is a very cost-effective k-band millimeter-wave radar sensor system with a detection range of up to 300 meters. It adopts the CW modulation mode to detect the speed and direction of moving targets, with high speed measurement accuracy.

The NST-TSR01 uses advanced SiGe MMIC technology to measure the speed and direction of a moving vehicles.

NST-TSR01 uses low sidelobe array antenna design technology to effectively avoid additional interference caused by beam divergence. The azimuth plane -3dB beam width is about 6.7 °, and the elevation plane -3dB beam width is about 27 °.

 NST-TSR01 is a multi-lanes single object speed radar, it adopts advanced MMIC and signal processing technology, with high capture rate, accurate speed measuring, stable performance, and can be widely used in road traffic speed measuring system and other fields.The product can help reduce drivers' speeding violations and avoid road traffic accidents caused by over speed driving.
