Product Description
Model No. | NST-ATC5902-MD |
| Camera Type | Outdoor Motion Detection Alarm Dual Light HD 1080P Coaxial Security Camera |
| Effective Pixels | 2.0 Mega Pixels 1080P(25/30fps) |
| Image Sensor | 1/2.9" SONY CMOS,WDR,UTC/OSD |
| DSP | Nextchip 2441 |
| Min. Illumination | Color 0.01Lux@F1.2 |
B/W 0.01 Lux@F1.2 | |
| Signal System | AHD/TVI/CVI/CVBS or PAL/NTSC |
| On Screen Display | Yes,UTC |
| OSD Function | 1080P 30/25FPS,
WDR 3D-DNR,
Sens-up x2 x4 x8,
Digital Zoom 16x Manual/DC Lens,Shutter/AGC/WB,Pict Adjust,Mirror,Day/Night,DNR,BLC/HLC,Motion Detect,Privacy Zone |
| IR Cut Filter | Set of double light switch IR-CUT filter |
| Lens Mount | Board Lens 3.6mm |
| Infrared Luminary | 2pcs Mini Array IR LEDs+2pcs Mini Array White LEDs |
| Infrared Wavelength | 850 nm |
| Illuminate Distance | 20m |
| Waterproof Criterion | IP65 |
| I/O Connector | 1*DC Power Connector ,1* BNC Video Connector |
| Supplied Voltage | DC12V |
| Power Consumption | Less than 200mA |
| Working Enviroment | -10C~+60C, 10%~90% ( Built in Heater being optional added for enviroment lower than -20 ) |
| Weight | 1.0KG |
