Product Description
Features:
Binocular live body detection technology, effectively prevent the attacks such as photos, videos and models, etc. 99.5% recognition rate; Recognition speed<500ms; 2x face libraries, supports max. 22400 faces. Multiple arming periods settings;
●Temperature measurement:
Medical-grade high accuracy temperature measurement module; Measurement accuracy: ±0.2℃; Measurement distance:1-5CM; Abnormal temperature alarm (threshold adjustable)
●Face recognition + mask detection:
Face + mask recognition rate 85%, mask wearing tip;
●Voice broadcast: face recognition result, temperature normal or abnormaland mask wearing broadcast
●Max.100000 records save or export
Specifications:
|
Model No. |
NST-Face2029-WT |
||
|
Smart Function |
Face Recognition |
Live body detection |
Visible light + NIR binocular camera, accurate recognition. Live body detection and accurate recognition under various environments. Resist on the non-livings such as photos, videos and face models. |
|
Face comparison |
Built-in database, supports face capture and real-time comparison with the local data, and create a comparison log |
||
|
Recognition accuracy |
≥99.5% |
||
|
Recognition type |
1 : N |
||
|
Recognition speed |
<500ms |
||
|
Recognition distance |
0.5-2m |
||
|
Recognition height |
1.2-2.2m, angle adjustable |
||
|
Vertical angle |
60° |
||
|
Horizontal angle |
40° |
||
|
Multiple recognition mode |
Face recognition, face recognition + temperature measurement, temperature measurement |
||
|
Face library |
Built-in 16GB storage, supports max. 22400 pcs of faces |
||
|
Comparison records |
Max.100000 records, export available |
||
|
Temperature measurement |
Accuracy |
±0.2 ℃ |
|
|
Range |
23-46 ( ℃ ) |
||
|
Mode |
Non-touch wrist temperature measurement |
||
|
Distance |
1-5CM |
||
|
Alarm |
Abnormal temperature alarm (threshold adjustable) |
||
|
Face + mask detection |
Accuracy |
≥85% |
|
|
Mask wearing alert |
Voice broadcast |
||
|
Voice broadcast |
Multiple mode |
Face recognition authentication result broadcast, temperature normal or abnormal result broadcast and mask wearing or not alert broadcast |
|
|
Hardware |
Processor |
DSP |
Hi3516DV300 |
|
Image sensor |
Sensor type |
1/2.8" Progressive Scan CMOS |
|
|
Effective resolution |
2.0 mega-pixels, 1920*1080 |
||
|
Min. Lux |
Color 0.01Lux @F1.2(ICR); B/W 0.001Lux @F1.2 |
||
|
SNR |
≥50db(AGC OFF) |
||
|
WDR |
≥80db |
||
|
Lens |
Binocular camera: visible light lens + NIR lens |
||
| Focal length |
4.mm |
||
|
Screen |
Size |
8” |
|
|
Resolution |
800*1280 |
||
|
Display scale |
16:9 |
||
| Temperature measurement solution | Infrared | ||
|
Audio |
Speaker |
2* (8Ω 1W) |
|
|
Interfaces |
Network |
RJ45 10M/100M self-adaptive Ethernet port |
|
|
Wiegand port |
1/1 I/O (26/34) |
||
|
USB port |
1x (connect the external ID identifier) |
||
|
Others |
Power supply |
DC 12V |
|
|
Power consumption |
20W(MAX) |
||
|
Protective grade |
IP34 |
||
|
Working temperature |
0 ℃ ~ 50 ℃ |
||
|
Working humidity |
5~90%, no condensation |
||
|
Dimension |
151.5 (W) *82.5(T) *307.3(H)mm |
||
|
N. weight |
2kg |
||
|
Stand diameter |
33mm |
||
|
Remark |
Default DC12V power adapter |
||
